■UCL-330 Close-up Lens

click to enlarge
M67シリーズレンズ

          Compatible Mount
          M67 Mount28LD Mount

●The UCL-330 is standard close-up lens with 33cm focal length to shorten minimum focus distance allowing you to get closer to a subject enabling high magnification close-up photography.

●Dual use underwater / land and usable with all zoom range. Even at same shooting distance, it is easy to capture a subject at desired size by adjusting zoom setting.

●The lens is constructed of two plano-convex high quality optical glass elements with inner coating to suppress optical aberrations more effectively comparing to a lens using just one double-convex element, and bring out optimal performance of combined master lens.

●The lens body has screw mount on its front end to stack other UCL-330 for even higher magnification macro imaging. Off course the UCL-165M67 can be stacked as well for further close-up shooting. The threaded part has a slit to drain water from gap between two lenses to easily separate combined lens underwater.

●Highly versatile screw type "M67 Mount" compatible.

●The UCL-330 is directly screwed on a housing which has M67 lens ring. For a housing which does not have M67 lens ring, the UCL-330 is attached via dedicated "M67 Mount Base". For "28LD Mount Base" compatible housing, the UCL-330 is attached on "28LD Mount Base" via "M67-LD Mount Converter for UCL-330/165M67".

(*1) Optional "M67-LD Mount Converter for UCL-330/165M67" is necessary.

click to enlarge
Screw type M67 Mount

click to enlargeDirectly screwed in housing port

click to enlargeAttached via specific "M67 Mount Base" for each camera/housing model.

Sample images at telephoto end

クリックすると拡大します
UCL-165M67 x 2
Zoom: telephoto end
Working distance: 57mm / 2.2in
Shooting distance: 26 x 22mm (1.0 x 0.8in)

クリックすると拡大します
UCL-165M67 + UCL-330
Zoom: telephoto end
Working distance: 66mm / 2.6in
Shooting distance: 30 x 23mm (1.2 x 0.9in)

クリックすると拡大します
UCL-165M67 x 1
Zoom: telephoto end
Working distance: 101mm / 4.0in
Shooting distance: 37 x 28mm (1.5 x 1.1in)

クリックすると拡大します
UCL-330 x 2
Zoom: telephoto end
Working distance: 89mm / 3.5in
Shooting distance: 38 x 29mm (1.5 x 1.1in)

クリックすると拡大します
UCL-330 x 1
Zoom: telephoto end
Working distance: 139mm / 5.5in
Shooting distance: 49 x 37mm (1.9 x 1.5in)

クリックすると拡大します
without close-up lens
Zoom: telephoto end
Working distance: 218mm / 8.6in
Shooting distance: 73 x 55mm (2.9 x 2.2in)

Sample images at wide end

クリックすると拡大します
UCL-165M67
Zoom: wide end
Working distance: 70mm / 2.8in
Shooting distance: 78 x 58mm (3.1 x 2.3in)

クリックすると拡大します
UCL-330
Zoom: wide end
Working distance: 78mm / 3.1in
Shooting distance: 92 x 69mm (3.6 x 2.7in)

クリックすると拡大します
without close-up lens
Zoom: wide end
Working distance: 113mm / 4.4in
Shooting distance: 112 x 84mm (4.4 x 3.3in)

Stacked UCL-165M67/UCL-330 is attached
Stacked UCL-165M67/UCL-330 is attached

[When using a close-up lens]

*Depending on housing, shooting distance, angle of view etc., the lens may block the built-in flash light from illuminating the entire image. In such cases it is recommended to shoot with an external strobe or flashlight.

*A close-up lens provides maximum magnification at zoom telephoto end.

*Generally, a close up lens shortens the camera’s close focusing distance. With the UCL-165LD, you can place your camera closer to a subject, achieving a larger image. On the other hand, depending on zoom or aperture setting, it may be more difficult to obtain complete depth of field on a distant subject.

*Stacking multiple lenses may cause vignetting at zoom wide end. As you stack more lens, focusing distance gets short and depth of field gets shallow as well.
