INON Arm System [Connecting Parts]

The Clamp III links and locks ball-joints of Arm Body, Direct Base or Adapter. Its spectacle shape ball-joint receptacles are machined lightweight aluminum alloy to satisfy highly precised and durable requirement. The handle is designed to naturally fit to fingers and made by resin casting to enhance its operability to clamp ball-joints firmly with less power and easy to loosen to adjust relative angle of combined arms.

■Effective length: 36mm (1.4in)
■Weight: 53g (1.9oz) [air] / approx.33g (1.2oz) [underwater]

The Clamp is made of machined lightweight aluminum alloy and weighs only 55g / 1.9oz The thumbscrew type gives easy clamping and unclamping.
Not only allowing 360 degrees free oscillating movement between attached arm system, also gives approx. 80° movement along an extended line of attached arm.

■Weight: 55g (1.9oz) [air] / approx.35g (1.2oz) [underwater]

The Direct Base III is a fundamental part to attach on a base or housing to expand your system with a strobe or LED flashlight via arm system.
Directly attached on the "Grip Base D4", "Grip Base M1" or "D Holder" etc. or via optional "M6 Plate Direct Base III" or "M5 Plate Direct Base III" on a housing or other base products.
It is also possible to attach the Direct Base III on the middle of the "Stick Arm" or "Multi Ball Arm" via optional "M6 Joint".
The Direct Base III is attached on a strobe as well. Its ball-joint is made of metal not as like a plastic ball-joint of the "Z Adapter MV" or "YS Adapter MV", to provide rigid strobe positioning only by lightly fasten the "Clamp III".

■Full length: 45mm (1.8in)
■Effective length: 32mm (1.3in)
■Weight: 35g (1.2oz) [air] / approx.23g (0.8oz) [underwater]

■Compatible base/housing etc.
●Directly attached
Grip Base D4, Grip Base M1, D Holder, D Holder Extension Bar,
Port Arm for MRS, Port Arm for UFL-MR130 EFS60, Tripod Adapter

●Attached via optional "M6 Plate Direct Base III"
X-2 series Housing, X1-Z/LZ/NZ Housing
Holder II, Grip+Bar III Set, Holder II Grip Set, Holder Base,
Grip+Bar I Set, Grip+Bar II Set,
Grip Base DIII w/ Rubber Grip D, Grip Base DII w/ Rubber Grip D,
Other brands' housing/arm system (*1)
(*1) Compatible with 2 x M6 screw holes with 8mm or more depth and 13mm - 28mm center-to-center distance of screw holes.

●Attached via optional "M5 Plate Direct Base III"
Other brands' housing/arm system (*2)
(*2) Compatible with 2 x M5 screw holes with 6mm or more depth and 24mm - 28mm center-to-center distance of screw holes.

■Compatible arm
●Attached via optional "M6 Joint"
Stick Arm Body XS/SS/S/M/L
Multi Ball Arm Body S/ML/L/LL/XL (SS Body is not compatible)

■Compatible strobe etc.
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180, D-180S, Z-220, Z-220F, Z-220S

The "Multi Direct Base II WB" has two ball-joints to have two branches of arm enabling more sophisticated lighting such as using one strobe for a subject and the other strobe for background or using a strobe for still imaging and video light for footage.
Total 10 fixing holes (M6 x 6, M5 x 4) on its base provide flexible compatibility with major brands' housings/grips and attached thoroughly by two cap bolts.

■Full length: 97mm (3.8in)
■Effective length: 86mm (3.4in)
■Weight: 56g (2.0oz) [air] / approx.33g (1.2oz) [underwater]
■Package contents: M6 Cap Bolt x 2, M5 Cap Bolt x 2,
　　　　　　　　　　 M6 Flat Washer x 2, M5 Flat Washer x 2, Allen Wrench

■Compatible base/housing etc.
Grip Base D4, Grip Base M1, D Holder, D Holder Extension Bar,
Grip Base DIII w/ Rubber Grip D, Grip Base DII w/ Rubber Grip D,
Port Arm for MRS, Port Arm for UFL-MR130 EFS60, Tripod Adapter
Holder II, Grip+Bar III Set, Holder II Grip Set, Holder Base,
Grip+Bar I Set, Grip+Bar II Set,
X-2 series Housing, X1-Z/LZ/NZ Housing
Other brands' housing/arm system including Anthis, Kenko, SEA&SEA (*1)

(*1) INON INC. has not confirmed compatibility with specific product(s) from other manufactures. Before using, make sure to check if the product(s) from other manufactures is compatible and does not interfere other combined product(s)

An aluminum alloy base product to attach an arm etc. on the Grip Base D4 or System Base II. Total 10 fixing holes on its base provide flexible compatibility with major brands' housings/grips, and attached thoroughly by two cap bolts.

■Full length: 88mm (3.5in)
■Effective length: 76mm (3.0in)
■Weight: 46g (1.6oz) [air] / approx.28g (1.0oz) [underwater]
■Package contents: M6 Cap Bolt x 2, M5 Cap Bolt x 2,
　　　　　　　　　　 M6 Flat Washer x 2, M5 Flat Washer x 2, Allen Wrench

■Compatible base/housing etc.
Grip Base D4, Grip Base M1, D Holder, D Holder Extension Bar,
Grip Base DIII w/ Rubber Grip D, Grip Base DII w/ Rubber Grip D,
Port Arm for MRS, Port Arm for UFL-MR130 EFS60, Tripod Adapter
Holder II, Grip+Bar III Set, Holder II Grip Set, Holder Base,
Grip+Bar I Set, Grip+Bar II Set,
X-2 series Housing, X1-Z/LZ/NZ Housing
Other brands' housing/arm system including Anthis, Kenko, SEA&SEA (*1)

(*1) INON INC. has not confirmed compatibility with specific product(s) from other manufactures. Before using, make sure to check if the product(s) from other manufactures is compatible and does not interfere other combined product(s)

An aluminum alloy base product to attach an etc. arm on the Grip Base D4 or System Base II. Total 10 fixing holes on its base provide flexible compatibility with major brands' housings and grips, and attached thoroughly by two cap bolts.

■Full length: 61mm (2.4in)
■Effective length: 40mm (1.6in)
■Weight: 36g (1.3oz) [air] / approx.22g (0.8oz) [underwater]
■Package contents: M6 Cap Bolt x 2, M5 Cap Bolt x 2,
　　　　　　　　　　 M6 Flat Washer x 2, M5 Flat Washer x 2, Allen Wrench

■Compatible base/housing etc.
Grip Base D4, Grip Base M1, D Holder, D Holder Extension Bar,
Grip Base DIII w/ Rubber Grip D, Grip Base DII w/ Rubber Grip D,
Port Arm for MRS, Port Arm for UFL-MR130 EFS60, Tripod Adapter
Holder II, Grip+Bar III Set, Holder II Grip Set, Holder Base,
Grip+Bar I Set, Grip+Bar II Set,
X-2 series Housing, X1-Z/LZ/NZ Housing
Other brands' housing/arm system including Anthis, Kenko, SEA&SEA (*1)

(*1) INON INC. has not confirmed compatibility with specific product(s) from other manufactures. Before using, make sure to check if the product(s) from other manufactures is compatible and does not interfere other combined product(s)

An adapter to attach INON "S-2000", "Z-240", "D-2000", "Z-220" or "D-180" series strobe on an arm body or Direct Base III etc. via Clamp III. The ball-joint is made from plastic to provide flexible strobe positioning without loosening a clamp to provide enormously comfortable strobe aiming.

■Full length: 76mm (3.0in)
■Effective length: 58mm (2.3in)
■Weight: 35g (1.2oz) [air] / approx.16g (0.6oz) [underwater]

■Compatible strobe etc.
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180, D-180S, Z-220F, Z-220F, Z-220S
Double Light Holder LE, Quad Light Holder LE, Strobe Light Holder LE

A joint adapter to attach INON S-2000, Z-240, D-2000 series strobe on YS type arm head including Grip Base D4, D Holder, YS Adapter, YS Arm and Shoe Base etc.

■Effective length: 26mm (1.0in)
■Weight: 45.5g (1.6oz) [air] / approx.23g (0.8oz) [underwater]

■Compatible strobe etc.
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180 (*1), D-180S,
Z-220 (*1), Z-220F, Z-220S (*1)
Strobe Light Holder LE, Double Light Holder LE, Quad Light Holder LE

■Compatible base/arm etc.
Shoe Base, YS Adapter MV, Double YS Adapter MV, YS Adapter WB MV,
YS Adapter, YS Arm M ,YS Arm MS ,Bar Mount
Grip Base D4, Grip Base M1, D Holder, D Holder Extension Bar,
Port Arm for MRS, Port Arm for UFL-MR130 EFS60

(*1) There are two Arm Base design depending on production lot and only trapezoidal version can accept this product.

An adapter to attach YS joint compatible product such as INON Z-22, SEA&SEA YS series strobe, Single Light Holder LE or Z Joint, on an arm or Direct Base III via a clamp. The ball-joint is made from plastic to provide flexible strobe positioning without loosening a clamp to provide enormously comfortable strobe aiming.

■Full lensgth: 67mm (2.6in)
■Effective length: 45.5mm (1.8in)
■Weight: 20g (0.7oz) [air] / approx.7g (0.2oz) [underwater]

■Compatible strobe/LED flashlight etc.
●Directly attached
INON Z-22, SEA&SEA YS series strobe
(excluding particular model such as YS-300, YS-350 etc.)

●Attached via optional "Z Joint"
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180 (*1), D-180S,
Z-220 (*1), Z-220F, Z-220S (*1)
Strobe Light Holder LE, Double Light Holder LE, Quad Light Holder LE

●Attached via optional "YS Adapter Fixing Bolt"
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180, D-180S, Z-220, Z-220F, Z-220S

●Attached via optional "Single Light Holder LE"
LE550-W, LE550-S, LE240, LE250

(*1) Particular production lot of "Z-220", "Z-220S", "D-180" is not compatible with the "Z Joint". Refer to "Z Joint" section for detail.

An aluminum alloy adapter to attach YS joint compatible product such as INON Z-22, SEA&SEA YS series strobe, Single Light Holder LE or Z Joint. SEA&SEA YS-300 and YS-350 has wider strobe adapter mount and YS Adapter is still usable for them by installing packaged O-ring on a groove of the adapter to accommodate with the strobe adapter mount.

■Full lensgth: 60mm (2.4in)
■Effective length: 58mm (2.3in)
■Weight: 45g (1.6oz) [air] / approx.29g (1.0oz) [underwater]

■Compatible strobe/light etc.
●Directly attached
INON Z-22, SEA&SEA YS Series Strobe

●Attached via optional "Z Joint"
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180 (*1), D-180S,
Z-220 (*1), Z-220F, Z-220S (*1)
Strobe Light Holder LE, Double Light Holder LE, Quad Light Holder LE

●Attached via optional "YS Adapter Fixing Bolt"
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180, D-180S, Z-220, Z-220F, Z-220S

●Attached via optional "Single Light Holder LE"
LE550-W, LE550-S, LE240, LE250

(*1) Particular production lot of "Z-220", "Z-220S", "D-180" is not compatible with the "Z Joint". Refer to "Z Joint" section for detail.

A strobe/LED flashlight adapter equipped with two YS type arm heads on a ball-joint to hold two strobe/LED flashlight via "Z Joint" or light holder.
The ball-joint is made from plastic to provide flexible strobe/LED flashlight positioning without loosening Clamp III.

■Full lensgth: 113mm (4.4in)
■Effective length: 91mm (3.6in)
■Weight: 30g (1.1oz) [air] / approx.11g (0.4oz) [underwater]

■Compatible strobe/light etc.
●Directly attached
INON Z-22, SEA&SEA YS series strobe
(excluding particular model such as YS-300, YS-350 etc.)

●Attached via optional "Z Joint"
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180 (*1), D-180S,
Z-220 (*1), Z-220F, Z-220S (*1)
Strobe Light Holder LE, Double Light Holder LE, Quad Light Holder LE

●Attached via optional "YS Adapter Fixing Bolt"
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180, D-180S, Z-220, Z-220F, Z-220S

●Attached via optional "Single Light Holder LE"
LE550-W, LE550-S, LE240, LE250

(*1) Particular production lot of "Z-220", "Z-220S", "D-180" is not compatible with the "Z Joint". Refer to "Z Joint" section for detail.

A strobe/LED flashlight adapter carrying double ball-joints. Strobes or LED flashlights are attached on the YS Arm compatible arm via "Z Joint" or light holder and on the ball-joint via "Clamp III" etc.
The ball-joint is made from plastic to provide flexible strobe/LED flashlight positioning without loosening Clamp III.

*This product is not designed to attach an extra arm. Attaching extra arm will damage the adapter itself.

■Full length: 122mm (4.8in)
■Effective length: 100.5mm (4.0in)
■Weight: 37g (1.3oz) [air] / approx.13g (0.5oz) [underwater]

■Compatible strobe/light etc.
●Directly attached
INON Z-22, SEA&SEA YS series strobe
(excluding particular model such as YS-300, YS-350 etc.)

●Attached via optional "Z Joint"
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180 (*1), D-180S,
Z-220 (*1), Z-220F, Z-220S (*1)
Strobe Light Holder LE, Double Light Holder LE, Quad Light Holder LE

●Attached via optional "YS Adapter Fixing Bolt"
S-2000, Z-240, D-2000,
D-2000S, D-2000W/Wn, D-180, D-180S, Z-220, Z-220F, Z-220S

●Attached via optional "Single Light Holder LE"
LE550-W, LE550-S, LE240, LE250

(*1) Particular production lot of "Z-220", "Z-220S", "D-180" is not compatible with the "Z Joint". Refer to "Z Joint" section for detail.

An adapter to attach Nikon SB strobe series on an Arm body or Float Arm via Clamp.

■Effective length: 45mm (1.8in)
■Weight: 45.6g (1.6oz) [air] / approx.31.0g (1.1oz) [underwater]

■Compatible strobe
Nikon SB103, SB105

An adapter to attach INON S-2000 strobe, Z-240 strobe, D-2000 strobe series, Z-220 strobe series or D-180 strobe series on an Arm body or Float Arm via Clamp.

■Effective length: 58mm (2.3in)
■Weight: 57g (2.0oz) [air] / approx.37g (1.3oz) [underwater]

■Compatible strobe
S-2000, Z-240, D-2000, D-2000S, D-2000W/Wn
D-180, D-180s, Z-220F, Z-220, Z-220S

An adapter to attach single INON LE series LED flashlight on "YS Adapter compatible arm". Especially for handy and compact camera system set-up with INON "Shoe Base" or "Grip Base D4".

■Weight: 56g (2.0oz) [air] / approx.31g (1.1oz) [underwater]

■Compatible LED Light
LE250, LE240, LE550-S, LE-550W

■Compatible Arm
●Directly attached
Shoe Base, Grip Base D4, D Holder, D Holder Extension Bar
YS Adapter MV, Double YS Adapter MV, YS Adapter WB MV
YS Adapter, YS Am MS, YS Arm M, Bar Mount
Port Arm for MRS, Port Arm for UFL-MR130 EFS60

An adapter to attach 2 x INON LE series LED flashlights on "YS Adapter" compatible arm via optional INON "Z Joint" or on INON "Arm System" via "Z Adapter MV". Ideal for photography / videography requiring certain amount of light.

　　　Z Joint■Weight: 72.5g (2.6oz) [air] / approx.29g (1.0oz) [underwater]

■Compatible LED Light
LE250, LE240, LE550-S, LE-550W

■Compatible Arm
●Attached via optional "Z Joint"
Shoe Base, Grip Base D4, D Holder, D Holder Extension Bar
YS Adapter MV, Double YS Adapter MV, YS Adapter WB MV
　Z Adapter MVYS Adapter, YS Am MS, YS Arm M, Bar Mount
Port Arm for MRS, Port Arm for UFL-MR130 EFS60

●Attached via optional "Z Adapter MV"
アームボール部を有したアームシステム製品

An adapter to attach 2 or 4 INON LE series LED flashlights on "YS Adapter" compatible arm via optional INON "Z Joint" enabling you to adjust light amount from single up to maximum four LE series lights depending on shooting situation.また、別途「ZアダプターMV」と組み合わせる事で、イノン「アームシステム」へ取り付けが可能。

　　　Z Joint■Weight: 115g (4.1oz) [air] / approx.48g (1.7oz) [underwater]

■Compatible LED Light
LE250, LE240, LE550-S, LE-550W

■Compatible Arm
●Attached via optional "Z Joint"
Shoe Base, Grip Base D4, D Holder, D Holder Extension Bar
YS Adapter MV, Double YS Adapter MV, YS Adapter WB MV
　Z Adapter MVYS Adapter, YS Am MS, YS Arm M, Bar Mount
Port Arm for MRS, Port Arm for UFL-MR130 EFS60

●Attached via optional "Z Adapter MV"
アームボール部を有したアームシステム製品

Optional product to attach one or two INON LE series LED flashlight on compatible lighting arm together with INON "S-2000", "D-2000" or "Z-240" etc. providing flexible lighting source selection. Usable as lighting arm to hold LE series LED flashlight only as well. 別途「Zジョイント」と組み合わせる事で､「シューベース」や「グリップベースD4」などの､「YSアダプター」互換アームへ、直接取り付け可能。また､別途「ZアダプターMV」/「Zアダプター」と組み合わせる事で､イノン「アームシステム」へ取り付け可能。

■Weight: 67.2g (2.4oz) [air] / approx.35g (1.2oz) [underwater]

　　　Z Joint■Compatible LED Light
LE250, LE240, LE550-S, LE-550W

■Compatible Strobe
S-2000, Z-240, D-2000
D-2000S, D-2000W/Wn, D-180(*1), D-180S
Z-220F, Z-220S(*1)

■Compatible Arm
　Z Adapter MV●Attached via optional "Z Joint"
Shoe Base (*2), Grip Base D4 (*2), D Holder,
D Holder Extension Bar
YS Adapter MV, Double YS Adapter MV, YS Adapter WB MV
YS Adapter, YS Am MS, YS Arm M, Bar Mount
Port Arm for MRS, Port Arm for UFL-MR130 EFS60

●Attached via optional "Z Adapter MV"/ "Z Adapter"
アームボール部を有したアームシステム製品

(*1) There are two Arm Base design depending on production lot and only trapezoidal version can accept this product.


(*2) "Wireless Connection" is not compatible when using this product to attach an external strobe since combined LED flashlight etc. on this product may block installation/free movement of a Mirror Unit (Strobe) which is necessary for "Wireless Connection", where most likely the built-in flash light may not be properly detected. Use "Optical Cable Connection" with compatible optical cable product like "Optical D Cable Type L / Cap Set" to connect between an external strobe and camera's built-in flash.
