UCL-165 M67

UCL-165M67 Close-up Lens

JAN code : 4562121439795

Click to enlarge
M67 Series Lens

Compatible Mount
M67 Mount
28LD Mount


M67 Mount
Screw type M67 Mount

The UCL-165M67 is high magnification close-up lens providing 165mm focal length (+6 diopter) where 165mm shooting distance from lens surface when camera’s focus position is set to infinity. Using minimum focusing distance will shorten minimum focus distance allowing you to get closer to a subject enabling high magnification close-up photography.

Dual use underwater / land and usable with all zoom range. Even at same shooting distance, it is easy to capture a subject at desired size by adjusting zoom setting.

The lens construction is 2 elements in 2 groups with high quality optical glass with inner coating to suppress optical aberrations more effectively and bring out optimal performance of combined master lens comparing to a lens using just one double-convex element.

The lens body has screw mount on its front end to stack other UCL-165M67 for even higher magnification macro imaging. Off course the UCL-330 can be stacked as well. The threaded part has a slit to drain water from gap between two lenses to easily separate combined lens underwater.

Highly versatile screw type "M67 Mount" compatible.

The UCL-165M67 is directly screwed on a housing which has M67 lens ring. For a housing which does not have M67 lens ring, the UCL-165M67 is attached via dedicated "M67 Mount Base" or "M67 Lens Adapter Base". For "28LD Mount Base」compatible housing, the UCL-165M67 is attached on "28LD Mount Base" via "M67-LD Mount Converter for UCL-330/165M67".

(*1) Optional "M67-LD Mount Converter for UCL-330/165M67" is necessary.


Click to enlarge

Directly screwed in housing port

click to enlarge

Attached via specific「M67 Mount Base」for each camera / housing model.

page top

Sample movie

081

Video by Korechika Yano
UWL-95S / UCL-67
UCL-90 / UCL-165
UCL-330 / UFL-M150 ZM80
079

Video by Toru Kasuya
UFL-M150 ZM80/UWL-95S XD
UCL-330/UCL-165 XD
Dome Lens Unit IIIG
078

Video by Korechika Yano
UFL-M150 ZM80/UWL-95S XD
UCL-330/UCL-165 XD
Dome Lens Unit IIIG
072

Video by Korechika Yano
UCL-165M67
LF2400h-EW

050

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UFL-M150 ZM80/UCL-330
LF2400h-EW
049

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
LF3100-EW
048

Video by Korechika Yano
UCL-90 M67/UCL-165M67
LF3100-EW

047

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
LF3100-EW
042

Video by Korechika Yano
UCL-90 M67/UCL-165M67


041

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330

033

Video by Korechika Yano
UCL-165LD


031

Video by Korechika Yano
UCL-165M67/UCL-100LD
LF2700-W

028

Video by Korechika Yano
UCL-165LD/UFL-M150 ZM80
UCL-330

024

Video by Korechika Yano
UCL-165LD/UFL-M150 ZM80
UCL-330/UCL-100LD

081

Video by Korechika Yano
UWL-95S / UCL-67
UCL-90 / UCL-165
UCL-330 / UFL-M150 ZM80
079

Video by Toru Kasuya
UFL-M150 ZM80/UWL-95S XD
UCL-330/UCL-165 XD
Dome Lens Unit IIIG
078

Video by Korechika Yano
UFL-M150 ZM80/UWL-95S XD
UCL-330/UCL-165 XD
Dome Lens Unit IIIG
072

Video by Korechika Yano
UCL-165M67
LF2400h-EW
050

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UFL-M150 ZM80/UCL-330
LF2400h-EW
049

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
LF3100-EW
048

Video by Korechika Yano
UCL-90 M67/UCL-165M67
LF3100-EW
047

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
LF3100-EW
042

Video by Korechika Yano
UCL-90 M67/UCL-165M67
041

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
033

Video by Korechika Yano
UCL-165LD
031

Video by Korechika Yano
UCL-165M67/UCL-100LD
LF2700-W
028

Video by Korechika Yano
UCL-165LD/UFL-M150 ZM80
UCL-330
024

Video by Korechika Yano
UCL-165LD/UFL-M150 ZM80
UCL-330/UCL-100LD

Sample images at telephoto end

クリックすると拡大します
UCL-165M67 x 2
Zoom: telephoto end
Working distance: 57mm / 2.2in
Shooting distance: 26 x 22mm (1.0 x 0.8in)
クリックすると拡大します
UCL-165M67 + UCL-330
Zoom: telephoto end
Working distance: 66mm / 2.6in
Shooting distance: 30 x 23mm (1.2 x 0.9in)
クリックすると拡大します
UCL-165M67 x 1
Zoom: telephoto end
Working distance: 101mm / 4.0in
Shooting distance: 37 x 28mm (1.5 x 1.1in)
クリックすると拡大します
UCL-330 x 2
Zoom: telephoto end
Working distance: 89mm / 3.5in
Shooting distance: 38 x 29mm (1.5 x 1.1in)
クリックすると拡大します
UCL-330 x 1
Zoom: telephoto end
Working distance: 139mm / 5.5in
Shooting distance: 49 x 37mm (1.9 x 1.5in)
クリックすると拡大します
without close-up lens
Zoom: telephoto end
Working distance: 218mm / 8.6in
Shooting distance: 73 x 55mm (2.9 x 2.2in)

Sample images at wide end

クリックすると拡大します
UCL-165M67
Zoom: wide end
Working distance: 70mm / 2.8in
Shooting distance: 78 x 58mm (3.1 x 2.3n)
クリックすると拡大します
UCL-330
Zoom: wide end
Working distance: 78mm / 3.1in
Shooting distance: 92 x 69mm (3.6 x 2.7in)
クリックすると拡大します
without close-up lens
Zoom: wide end
Working distance: 113mm / 4.4in
Shooting distance: 112 x 84mm (4.4 x 3.3in)
Stacked UCL-165M67/UCL-330 is attached

[When using a close-up lens]

*Depending on housing, shooting distance, angle of view etc., the lens may block the built-in flash light from illuminating the entire image. In such cases it is recommended to shoot with an external strobe or flashlight.

*A close-up lens provides maximum magnification at zoom telephoto end.

*Generally, a close-up lens shortens the camera’s close focusing distance. With this product, you can place your camera closer to a subject, achieving a larger image. On the other hand, depending on zoom or aperture setting, it may be more difficult to obtain complete depth of field on a distant subject.

*Stacking multiple lenses may cause vignetting at zoom wide end. As you stack more lens, focusing distance gets short and depth of field gets shallow as well.
