Shoe Base Series

Shoe Base 1/4-20UNC

Shoe Base 1/4-20UNC1/4-20UNC Screw Type

Shoe Base M6

Shoe Base M6M6 Screw Type

Shoe Base BALL

Shoe Base BALLArm Ball Type

Shoe Base

Shoe BaseYS Type


Shoe Base 1/4-20UNC, M6, BALL

Base adapters to make simple yet compact strobe/light/action camera etc. installation on the "Accessory Shoe (Cold Shoe)" of an underwater housing etc. These improved Shoe Bases provide more secure installation on an accessory shoe.

Head parts differ among different model having either of "1/4 inch screw", "M6 screw" or "ball joint". All Shoe Bases are designed to separate head part and base part to use head part standalone for a tripod etc.

■Compatible products (Shoe Adapter)
Accessory Shoe of water-proof camera housings, "Mount Base" and "Video Base" etc.
Shoe Base Spacer
Shoe Base Adapter D4
Shoe Base Adapter X-2

Optional "Accessory Shoe Spacer for Canon" is required when installing these products on an accessory shoe of Canon housings.

Shoe Base 1/4-20UNC usage

■Shoe Base 1/4-20UNC

JAN code: 4562121438484

Shoe Base 1/4-20UNC
Shoe Base 1/4-20UNC usegeShoe Base 1/4-20UNC usege
Shoe Base 1/4-20UNC usegeShoe Base 1/4-20UNC usege

A Shoe Base equipped with "1/4-20UNC" male screw on its head adapter. The built-in ball head supports wide movable range (360-degree rotatable and 180-degree back and forth) yet with its compact body.
The Shoe Base 1/4-20UNC can be directly screwed on a conventional digital camera or underwater housing equipped with "1/4-20UNC" female screw hole at the bottom. An action camera or compact digital camera can be installed on an accessory shoe of an underwater housing to shoot/film simultaneously.
The INON "Single Light Holder LE/LF for Tripod" enables to combine INON LE/LF series LED flashlight with this Shoe Base.
The Shoe Base 1/4-20UNC is designed to separate upper "Head Adapter" and lower "Shoe Base Adapter" to use the "Head Adapter" standalone as a tripod head with 1/4 inch screw on a tripod etc.

■Full length: 72mm (2.8in)
■Weight: 78g (2.8oz) [air] / approx.45g (1.6oz) [underwater]

■Compatible products(Top 1/4-20UNC screw)
Single Light Holder LF for Tripod
Single Light Holder LE for Tripod
SD Mount Cage for HERO3/3+/4
SD Front Mask for HERO5/6 (with packaged "Mount Adapter ")
SD Front Mask STD (with packaged "Mount Adapter")
SD Mount Base for TG-Tracker (with packaged "Mount Adapter")
SD Mount Base UWH1 (with packaged "Mount Adapter")
Action camera/compact digital camera equipped with "1/4-20UNC" tripod screw hole (screw hole depth 5mm or deeper).

■Shoe Base M6

JAN code: 4562121438477

Shoe Base 1/4-20UNC
Shoe Base M6 usegeShoe Base M6 usege

Shoe Base M6 usege

A Shoe Base equipped with "M6 screw" male screw on its head adapter. The built-in ball head supports wide movable range (360-degree rotatable and 180-degree back and forth) yet with its compact body.
The Shoe Base M6 can directly hold an INON strobe or accessories for an action camera (SD Front Mask, SD Mount Base etc.) on their M6 screw hole. A strobe or an action camera can be installed on an accessory shoe of an underwater housing to make simple strobe configuration or shoot/film simultaneously.
The Shoe Base M6 is designed to separate upper "Head Adapter" and lower "Shoe Base Adapter". The "Head Adapter" can be used standalone as a tripod head with M6 screw to attach on a tripod etc.

■Full length: 77mm (3.0in)
■Weight: 69g (2.4oz) [air] / approx.40g (1.4oz) [underwater]

■Compatible products(Top M6 screw)
Z-330, S-2000, Z-240, D-2000, D-2000S, D-2000W/Wn, D-180, D-180S, Z-220, Z-220S, Z-220F
SD Mount Cage for HERO3/3+/4 (※)
SD Front Mask for HERO5/6
SD Front Mask STD
SD Mount Base for TG-Tracker
SD Mount Base UWH1

When installing this product to INON "SD Mount Cage for HERO3/3+/4", optional "Rubber Spacer" is required to attach on the SD Mount Cage (*Rubber Spacer is not packaged as standard accessory). So please consult your purchasing dealer if you attach this product on INON SD Mount Cage.

■Shoe Base BALL

JAN code: 4562121438521

Shoe Base BALL

A versatile Shoe Base equipped with "ball-joint" on its head to link with any adapter having a ball-joint via clamp to install strobe, light or action camera on an accessory shoe of an underwater housing.
The upper ball-joint part is removable to use standalone to attach on a tripod etc.

■Full length: 55mm (2.2in)
■Weight: 52g (1.8oz) [air] / approx.28g (1.0oz) [underwater]

■Compatible products(Top arm ball)
Clamp III
Clamp

Shoe Base BALL usegeShoe Base BALL usegeShoe Base BALL usegeShoe Base BALL usege

These Shoe Bases are designed to separate upper "Head Adapter" and lower "Shoe Base Adapter". All "Head Adapter" has 1/4 tripod screw hole on its bottom to attach on a tripod etc.
All "Head Adapters" are available separately while "Shoe Base Adapter" is identical among three Shoe Bases to create different combination only with an optional other type "Head Adapter".

The "Shoe Base 1/4-20UNC" and "Shoe Base M6" is equipped with a ball head. These two Shoe Bases have a "Locking Wingnut" on the side. Loosening the Locking Wingnut enables free 360-degree rotatable and 180-degree back and forth movement for flexible positioning while fixing the Locking Wingnut firmly fixed the position you select.

Shoe Base 1/4-20UNC, M6, BALL Accessories

Shoe Base Spacer

Shoe Base Spacer

Shoe Base Adapter D4

Shoe Base Adapter D4

Shoe Base Adapter X-2

Shoe Base Adapter X-2

Accessory Shoe Spacer for Canon


Single Light Holder LE for Tripod

Single Light Holder LE for Tripod

Single Light Holder LF for Tripod

Single Light Holder LF for Tripod

Clamp III

Clamp III

[Shoe Base 1/4-20UNC, M6, BALL Compatible Table] *Click to Open

<Remarks>
○: Compatible     ▲: Conditionally compatible     ―: Not compatible

■Compact Digital Camera
[Olympus] [Panasonic]
Camera Housing Compatible Note Camera Housing Compatible Note
TG-5 PT-058 LUMIX FT5 MCFT5 *1
TG-4 PT-056 LUMIX FT4 MCFT3
TG-3 LUMIX FT3
TG-835 PT-055 LUMIX FT2 MCFT2
TG-830 LUMIX FT1 MCFT1
XZ-2 PT-054 LUMIX TZ40 MCTZ40
TG-2 PT-053 LUMIX TZ35 MCTZ35
TG-1 LUMIX TZ30 MCTZ30
TG-820 PT-052 LUMIX TZ20 MCTZ20
TG-810 PT-051 LUMIX TZ10 MCTZ10
TG-610 LUMIX TZ7 MCTZ7
XZ-1 PT-050 LUMIX TZ5 MCTZ5
μTOUGH-8010 PT-048 LUMIX TZ3 MCTZ3
μTOUGH-6020 LUMIX ZX3 MCZX3
μTOUGH-6000 PT-047 LUMIX ZX1 MCZX3
FE-3010 PT-046 MCZX1
μTOUGH-8000 PT-045 LUMIX FX40 MCFX40
FE-360 PT-044 LUMIX FX37
MCFX35
μ1030SW PT-043 LUMIX FX35
μ1020 PT-040 LUMIX FX33
MCFX30
μ850SW PT-041 *1 LUMIX FX30
μ790SW LUMIX FX07
MCFX07
μ830 PT-039 MCFX01
μ780 LUMIX FX01 MCFX07
SP-560UZ PT-037 *3 MCFX01
SP-550UZ LUMIX FS3, FS5 MCFS5
μ760 PT-036 LUMIX FS2
MCFX07
μ795SW PT-035 *1*2 LUMIX FS1
μ770SW
μ750 PT-034 [FUJIFILM]
μ725SW PT-033 *1*2 Camra Housing Compatible Note
μ720SW FUJIFILM XQ2 WP-XQ1
μ710 PT-032 FUJIFILM XQ1
SP-700 PT-031 FinePix F600EXR WP-FXF500
SP-350 PT-030 FinePix F550EXR
μ600 PT-029 FinePix F300EXR
C-7070WZ PT-027 FinePix F80EXR WP-FXF80
μ-40 PT-026 FinePix Z250fd WP-FXZ100
X-3 PT-024 FinePix Z200fd
C-8080WZ PT-023 FinePix Z100fd
C-770UZ PT-022 FinePix F200EXR WP-FXF200
C-760UZ FinePix F100fd WP-FXF100
C-5060WZ PT-027 FinePix F50fd WP-FXF50
PT-020 FinePix F40fd WP-FXF40
C-755UZ PT-018 FinePix F31fd
WP-FXF30
C-750UZ FinePix F30
C-745UZ FinePix F11
WP-FXF10
C-740UZ FinePix F10
μ-30 PT-016 FinePix F810
WP-FX701
μ-25 FinePix F710
μ-20
μ-15 [Canon]
μ-10 Camera Housing Compatible Note
C-5050Z PT-015 PowerShot
G7 X Mark II
WP-DC55 *5
X-2 PT-014
X-1 PowerShot G7 X
WP-DC54 *5
C-40Z PT-012 PowerShot
G1 X Mark II
WP-DC53 *5
C-4100Z PT-010
C-4040Z PowerShot G16
WP-DC52 *5
C-3100Z PowerShot S120 WP-DC51 *5
C-3040Z PowerShot
SX280 HS
WP-DC49 *5
C-3030Z
C-3000Z PowerShot G15 WP-DC48 *5
C-2040Z PowerShot S110 WP-DC47 *5
C-2020Z PowerShot D20 WP-DC45 *5
C-300Z PT-009 PowerShot S100 WP-DC43 *4
C-200Z PowerShot S95 WP-DC38 *4
C-3040Z PT-007 PowerShot S90 WP-DC35 *4
C-3030Z
C-3000Z [Sony]
C-2040Z Camera Housing Compatible Note
C-2020Z DSC-RX100M5 MPK-URX100A
C-3030Z PT-005 DSC-RX100M4
C-3000Z DSC-RX100M3
C-2020Z DSC-RX100M2
  DSC-RX100
  DSC-WX200 MPK-WH *4
  DSC-WX100
  DSC-WX50

■Digiral SLR Camera
[Olympus] [Canon]
Camera Housing Compatible Note Camera Housing Compatible Note
OM-D E-M1 Mark II PT-EP14 EOS 80D X-2 for EOS80D *6
OM-D E-M5 Mark II PT-EP13 EOS 6D X-2 for EOS6D *6
PEN E-PL7 PT-EP12 EOS 70D X-2 for EOS70D *6
OM-D E-M1 PT-EP11 EOS 60D X-2 for EOS60D *6
PEN E-PL5 PT-EP10 EOS 50D X-2 for EOS50D/40D *6
OM-D E-M5 PT-EP08 EOS 40D
PEN E-PM1 PT-EP06L EOS 30D X-2 for EOS30D *6
PEN E-PL3 PT-EP05L EOS 20D X-2 for EOS20D *6
PEN E-PL2 PT-EP03 EOS 10D X-2 for EOS10D *6
PEN E-PL1 PT-EP01
E-620 PT-E06
E-520 PT-E05
E-410 PT-E03 *3
  [Nikon]
[Panasonic]       Camera Housing Compatible Note
Camera Housing Compatible Note NIKON 1 J4 WP-N3
LUMIX GF2 X-2 for GF2 *6 NIKON 1 J3 WP-N2
LUMIX GF1 X-2 for GF1 *6 NIKON 1 J2 WP-N1

■Digital Video Camera
[Canon]
Camera Housing Compatible Note
iVIS HF M52 WP-V4 *4
iVIS HF M51
iVIS HF M43 WP-V3 *4
iVIS HF M41
iVIS HF M31 WP-V2 *4
iVIS HF21 WP-V1 *4
iVIS HF20 WP-V1 *4


(*1) Not usable together with "Mont Base" or "Lens Adapter Base".
(*2) When attaching on the Accessory Shoe of the housing, locate the Hook Plate nail of the respective Shoe Base [facing front].
(*3) An Optical D Cable Cap Set is not usable together with these Shoe Bases. Use Wireless Connection.
(*4) These Shoe Bases can be attached only via optional compatible Mount Base/Video Base.
(*5) "Accessory Shoe Spacer for Canon" is necessary.
(*6) "Shoe Base Adapter X-2" is necessary.
