UCL-G165 SD Underwater Wide Close-up Lens
[Discontinued]
The INON "UCL-G165 SD" underwater wide close-up lens enables you to shoot a subject from close range of the lens to capture the subject larger in a frame.
Compatible camera
- OLYMPUS STYLUS TG-Tracker
- SONY FDR-X3000/X3000R
- SONY HDR-AS300/AS300R
- GoPro® HERO11 Black
- GoPro® HERO10 Black
- GoPro® HERO9 Black
- GoPro® HERO8 Black
- GoPro® HERO7 Black
- GoPro® HERO6 Black
- GoPro® HERO5 Black
- GoPro® HERO+LCD
- GoPro® HERO+
- GoPro® HERO
- GoPro® HERO4
- GoPro® HERO3+
- GoPro® HERO3
Get Closer Minimum Focus Distance
An action camera is a deep focus camera which does not require focusing but prevents a subject gets in focus in close range (within 60cm/2ft range in theory for GoPro® camera) thus not usable for underwater macro shooting. Using standard macro lens for a compact digital camera would not help the situation as it would create vignetting and very shallow depth of field preventing comfortable focusing. The UCL-G165 SD lens is so-called "wide close-up lens" specifically designed for action cameras based on their optical characteristic. The depth of field (DoF) underwater will be 5cm/2.0in to 35cm/1.1ft when using the lens for GoPro® HERO11 Black supporting closer minimum focus distance underwater to capture wow photos/clips.
* The depth of field (DoF) on land is theoretical value based on focal length/aperture of camera lens and pixel pitch of the image sensor. DoF underwater is measured from "the forefront of the lens".
Ideal Angle of View for Macro Shooting
Maximum angle of view of GoPro® HERO11 Black Black is approx. 156° on land which will narrow down to approx. 94° when the camera is housed in genuine dive housing and submerged due to different refraction index. The INON UCL-G165 SD slightly increases angle of view underwater to 110° to capture dynamic scene played by a subject as the lens frames subject larger than UFL-G140 SD which delivers ultra wide 140°.
※Measured angle of view by INON on land or calculated angle of view underwater based on the measured angle of view on land. Not confirmed by camera manufacture.
Professional-level Image Quality
Optics is constructed of 2 elements in 2 groups. All elements are made from high refractive index glass lens to minimize whole size dramatically without sacrificing performance. Both lens elements have anti-reflection coating on all surfaces to elicit combined master lens performance with less ghost/flare.
*Note that a lens adapter other than INON SD Front Mask may degrade image quality significantly as such adapter is not optimized for use with INON lens. Using such an adapter is not recommended and may void product warranty.
Speedy Lens Exchange by SD Mount
Bayonet INON SD Mount compatible to support friendly and speedy lens exchange underwater. Compatible with AD Lens Holder to hold a lens when not in use.
[Options]
AD/SD
Rear Replacement Lens Cap
UCL-G165 SD
Front Replacement Lens Cap
Compatible Accessories
AD Lens Holder for Float Arm
AD Lens Holder
UCL-330 Neoprene Carry Pouch
| Size | 77mm / 3.0in (Diameter), 25.2mm / 1.0in (Length) |
| Weight | [air] 200g / 7.1oz [underwater] approx. 121g / 4.3oz |
| Mount system | INON SD Mount |
| Depth rating | 60ｍ / 196.9ft |
| Body material/finishing | Corrosion-resistant aluminum alloy / rigid black alumite, PC etc. |
| Lens material/coating | Optical glass / both side coating |
| Lens construction | 2 groups 2 elements |
| Max. view angle (*1) | 165mm (underwater) |
(*1) Standalone focal length of UCL-G165 SD and not combined focal length with camera’s master lens.
| Mfr. | Camera | Depth of field with UCL-G165 SD (*2) |
| GoPro (*3) | HERO11 Black HERO10 Black HERO9 Black HERO8 Black HERO7 Black HERO6 Black HERO5 Black HERO4 HERO3+ Black HERO HERO+ HERO+ LCD |
5cm / 2.0in to 35cm / 1.1ft |
| HERO3 BLACK | 7cm / 2.8in to ∞ | |
| OLYMPUS | TG-Tracker | 2cm / 0.8in to 15cm / 5.9in |
| SONY | FDR-X3000 HDR-AS300 |
5cm / 2.0in to 35cm / 1.1ft |
(*2) Measured DoF from foreground of the lens surface. Divide by 1.33 for visual distance underwater.｡
(*3) Measured distance underwater for GoPro® HERO11 Black/HERO10 Black/HERO9 Black/HERO8 Black/HERO7 Black/HERO6 Black/HERO5 Black/HERO4/HERO3+ Black/HERO3 Black/HERO/HERO+/HERO+ LCD. Other Edition has not been tested.
[When using the UCL-G165 SD]
* The UCL-G165 SD is designed only for underwater use. Using the lens on land will have vignetting.
[When using for GoPro®]
* Set the camera's field of view (FOV)/Digital Lenses to [Wide] for wide-angle macro photography that prioritizes angle of view, or [Narrow] for magnification-oriented photography.
* When using with HERO Black 11, shoot in 4:3 or 16:9 aspect ratio as vignetting will occur in 8:7 or HyperView mode.
* [SuperView™] mode is not recommended. The SuperView™ mode stretches both ends of the image inside the camera to fit into a 16:9 aspect ratio from originally obtained 4:3 aspect ratio image by the camera sensor. Since the edges of the frame are stretched horizontally, using an attachment lens further stretches the edges of the frame, resulting in an unnatural image.
* Set the camera's image stabilization (HyperSmooth) to [Standard], [High], or [On]. Setting to [Off] will cause vignetting in image corners, and [Boost] will crop the image significantly.
* The FOV/Digital Lenses setting [Wide] in Photo mode causes vignetting in image corners.
* Since this lens provides ultra wide angle of view, it is recommended to set Spot Meter to [ON] when using external lighting source (LED flashlight etc.). Setting Spot Meter to [OFF] may have washout if the external lighting device aims center of the frame.
[When using for TG-Tracker]
* Activate image stabilization function of the camera while shooting video to avoid vignetting. When taking still images, do not use attachment lens to avoid significant vignetting on image corners.
* Since the camera is designed to offer optimal focusing performance for close range subject, usable range of DoF (depth of field) with this lens is "2cm/0.8in to 15cm/5.9in" and distant subject beyond this range gets blur.
[When using for FDR-X3000/HDR-AS300]
* Select SteadyShot (Movie) [Act] when shooting video as [Std] and [OFF] cause slight vignetting. Select SteadyShot (Still) [ON] when shooting still image. Excessive camera movement may result vignetting even SteadyShot (Movie) [Act] is selected.
* Set angle of view to [W: Wide] for wide-angle macro shooting that prioritizes angle of view, or [N: Narrow] for magnification-oriented imaging.
Sample Movie
Video by Toru Kasuya
UCL-G165 SD
Video by Takehiro Aihara
UFL-G140 SD
UCL-G165 SD
Video by Korechika Yano
UFL-G140 SD
UCL-G165 SD
Video by Akihide Inoue
UFL-G140 SD
UCL-G165 SD
Video by Ryo Hattori
UCL-G165 SD
LF1100-W
Video by Mateusz Bednarcuzk
UCL-G165 SD
UFL-G140 SD
UCL-G165 SD
Video by Toru Kasuya
UCL-G165 SD
Video by Takehiro Aihara
UFL-G140 SD
UCL-G165 SD
Video by Korechika Yano
UFL-G140 SD
UCL-G165 SD
Video by Akihide Inoue
UFL-G140 SD
UCL-G165 SD
Video by Ryo Hattori
UCL-G165 SD
LF1100-W
Video by Mateusz Bednarcuzk
UCL-G165 SD
UFL-G140 SD
UCL-G165 SD
